MARCA :TPL COMMUNICATIONS
Silicon RF Power MOSFET Power Transistor, 175 MHz, 530 MHz, 70W
Silicon RF Power MOSFET Power Transistor, 175 MHz, 530 MHz, 70W
MODELO:
SKU:B2-224
- ENVIAMOS A TODA LA REPUBLICA MEXICANA
Los precios pueden cambiar diariamente debido al tipo de cambio
Agotado
SI TU PRODUCTO APARECE COMO "AGOTADO", CONTÁCTANOS Y UN ASESOR TE DARA LA NUEVA FECHA DE STOCK. PARA PRODUCTOS "SOBRE PEDIDO" TE PROPORCIONAREMOS UNA FECHA DE ENTREGA ESTIMADA.
No se pudo cargar la disponibilidad de retiro
DESCRIPTION
RD70HUF2 is MOS FET type transistor specifically designed for VHF/UHF RF power amplifiers applications.
FEATURES
1. Supply with Tape and Reel. 500 Units per Reel 2. Employing Mold Package
3. High Power and High Efficiency
Pout=75Wtyp, Drain Effi.=64%typ
@ Vds=12.5V Idq=1.0A Pin=5.5W f=530MHz
Pout=84Wtyp, Drain Effi.=74%typ
@ Vds=12.5V Idq=1.0A Pin=4.0W f=175MHz
4. Integrated gate protection diode
APPLICATION
For output stage of high power amplifiers in VHF/UHF band mobile radio sets.
RoHS COMPLIANT
RD70HUF2 is a RoHS compliant product. RoHS compliance is indicating by the letter “G” after the Lot Marking. This product includes the lead in high melting temperature type solders.
However, it is applicable to the following exceptions of RoHS Directions.
1. Lead in high melting temperature type solders. (i.e. tin-lead solder alloys containing more than85% lead.)
